Unused outputs are shorted to earth.

Frequency Range: DC - 1 GHz
• Power Range:
…DC - 30 MHz 1.5 KW
…30 MHz - 200 MHz 1 KW
…200 MHz - 500 MHz 500 Watt
…500 MHz - 1 GHz 250 Watt
• Insertion Loss:
…DC- 500 MHz <=0.05 dB
…500 MHz - 1 GHz <=0.10 dB
• Output Port 1/2 Isolation:
…DC - 500 MHz >= 70 dB
…500MHz - 1 GHz >= 60 dB
• VSWR:
…DC - 500 MHz <=1.15
…500 MHz - 1 GHz <=1.25
• Connector Type:
…Input Port: 1 PL-259 Female
…Output Port: 3 PL-259 Female

PRICE €75
